Introduction:
The gene amplification instrument is an instrument that performs nucleic acid amplification by polymerase chain reaction.
Mainly used in medical institutions, clinical gene amplification testing laboratories that meet the requirements, scientific research institutes, universities, etc.
Technical Specification
| Capacity | 96 |
| Reaction Volume | 10~200μl |
| Tube Type | 96*0.2ml PCR plate; 8*0.2ml PCR tube; 0.2ml single PCR tube |
| Block Temperature Range | 4℃~105℃ |
| Heat Lid Temperature Range | 30℃~110℃ |
| Max Heating Rate | 4.0℃/s |
| Max Cooling Rate | 3℃/s |
| Display Resolution | 0.1℃ |
| Temperature Accuracy | ±0.3℃ |
| Temperature Uniformity | ±0.3℃ |
| Block Material | Aluminum |
| Gradient Range | 30~99℃ |
| Temperature Differential Range | 1~42℃ |
| Program | A single program can be up to 30 steps, 99 cycles |
| Display | 7″ LCD |
| Power Supply | 110V~220V, 50/60Hz |
| External Size(L*W*H) | 398*280*257mm |
| Net Weight | 11kg |
| Package Size(L*W*H) | 495*380*380mm |
| Gross Weight | 17kg |
