SMT-03H Ultrasonic Bone Densitometer
1.Suitable for a variety of population testing (pregnant women, adults and the elderly), detection age range 3-20/20 -100 years old.
2. Measurement site: heel bone
3. Probe: The oil bag probe uses characteristic ultrasonic oil as a conductor for measurement, and the probe automatically searches for the best signal. It does not need to be replaced during the life of the product and can be used permanently.
4. Complete calculation parameters: adult: T value, Z value, same age ratio, adult ratio, OPR (measurement repeatability), OI (bone mass index), SOS (sound velocity), BUA (ultrasonic amplitude attenuation), bone physiological age
Notice: You need to connect the host to your own computer and printer.
2. Measurement site: heel bone
3. Probe: The oil bag probe uses characteristic ultrasonic oil as a conductor for measurement, and the probe automatically searches for the best signal. It does not need to be replaced during the life of the product and can be used permanently.
4. Complete calculation parameters: adult: T value, Z value, same age ratio, adult ratio, OPR (measurement repeatability), OI (bone mass index), SOS (sound velocity), BUA (ultrasonic amplitude attenuation), bone physiological age
Notice: You need to connect the host to your own computer and printer.
Technical Specification
Ultrasonic parameters: BUA (Broadband Ultrasound Attenuation), SOS (Speed of Sound), OI (Osteogenic Index).
Measurement method: Fully dry-type (no temperature control device required) oil capsule probe measurement, bidirectional ultrasound transmission and reception. Radiation-free, suitable for testing various populations (children, pregnant women, adults, and the elderly). Recommended testing age range: 3–100 years.
Measurement site: Heel bone.
Probe: The oil capsule probe uses specialized ultrasound oil as a conductor for measurement. The probe automatically searches for the optimal signal and does not require replacement during the product’s lifespan; it can be used permanently.
Probe frequency: 0.5 MHz ±15%.
Measurement time: ≤25 seconds (actual test: 21 seconds).
Test repeatability: SOS ≤1% (actual test: 0%).
Measurement error: SOS ≤±2% (actual test: 1%).
Test repeatability: BUA ≤5% (actual test: 0%).
Temperature compensation system: Automatically compensates for measurement deviations caused by temperature.
Comprehensive calculation parameters:
Adults: T-score, Z-score, age-matched ratio, adult-matched ratio, OPR (measurement repeatability), OI (Osteogenic Index), SOS (Speed of Sound), BUA (Broadband Ultrasound Attenuation), bone physiological age.
Children: Z-score, BMI (Body Mass Index), height prediction, obesity degree, SOS (Speed of Sound), BUA (Broadband Ultrasound Attenuation), bone physiological age.
Animation playback function: Attracts children’s attention during examinations, making it easier for doctors to complete the procedure.
Device self-check function: Automatically prompts issues during testing, including setup errors, inaccurate module placement, and correct positioning of the test site.
Case database management system: Automatically records, queries, categorizes, and backs up data. Measurement results can be exported in formats such as EXCEL, JPG, PDF, and DOC.
Related Products
SMT-050DH Double column Digital Radiography System (Hand-driven)
Double column Digital Radiography System adopts large span independent ball tube frame design, easy installation, small occupation area, convenient maintenance. Four-way floating bed surface, easy to use and positioning. The lifting and lifting of X-ray source and bidirectional follow-up of horizontal position of bed column can reduce the positioning time and meet the requirements of large-flow clinical examination.
Applicable to orthopedics, emergency room, operating room, etc.,As human head, limbs, chest, spine, lumbar spine for medical diagnosis
VSM-3200T 32kW 400mA Veterinary Digital Radiography System
1. Sophisticated technology, high rotating speed, good heat dissipation, high heat capacity, suitable for long-time clinical examination, long product life.
2. High frequency generator with high X-ray inverse frequency, large power and good X-ray quality.
3. Intelligence high voltage control system with various APR.
4. New generation a-Si Csl flat panel detector with high conversion rate achieves digital image acquisition with low dose.
5. High standard digital image processing system provides more post-processing and meets clinical needs.
SM-800L 2-8°C Medicine Refrigerator
Meet the requirements of the new version GSP for medicine storage.
Can be used for medicine, reagents and various items that need cold storage.
Suitable for hospitals, clinics, blood stations of health and epidemic prevention systems, university laboratories, etc.
SMH-60B 5-part Auto Hematology Analyzer
